BLD0510 Compact Linear Anti-glare Ceiling Grille 10W
BLD0510
Quick info
CCT: 2700K, 3000K, 4000K, 5700K, 6500K, 2700-6500K
CRI: CRI>90
Full Beam Angle: 15°/30°/45°
Dimmable: DALI, Triac, 0-10V, Bluetooth, Zigbee
Luminous Flux: 100Lm/W
Protection: IP20
Warranty: 3 years
CCT: 2700K, 3000K, 4000K, 5700K, 6500K, 2700-6500K
CRI: CRI>90
Full Beam Angle: 15°/30°/45°
Dimmable: DALI, Triac, 0-10V, Bluetooth, Zigbee
Luminous Flux: 100Lm/W
Protection: IP20
Warranty: 3 years
Description
The BLD0510 10W Compact Linear Anti-glare Ceiling Grille is crafted for precision accent lighting. Its advanced anti-glare optical design ensures comfortable, glare-free illumination while maintaining high CRI90 for accurate color rendering. With selectable 15°-60° beam angles, this surface-mounted fixture is the perfect choice for highlighting jewelry displays and fine art galleries, delivering focused lighting with a sleek, modern linear profile.
Contact us for project pricing or OEM samples.
Specification
| BLD0510 Compact Linear Anti-glare Ceiling Grille 10W | Size and drawing | ||||||||||||
| Product code | BLD0510 |  | |||||||||||
| Power | 10W | ||||||||||||
| Voltage | 220-240VAC | ||||||||||||
| CCT | 2700K, 3000K, 4000K, 5000K, 6500K, 2700K-6500K | ||||||||||||
| Size | D30xL75xH85mm | ||||||||||||
| Color tolerance | SDCM＜3 | ||||||||||||
| Beam angle | 15°/30°/45° | ||||||||||||
| Power factor | PF>0.9 | ||||||||||||
| CRI | CRI90+ | Dimming control | |||||||||||
| Dimmable | DALI, Triac, 0-10V, Bluetooth, Zigbee |  | |||||||||||
| Optics | Reflector | ||||||||||||
| Color Accuracy | Rf≥92 | ||||||||||||
| Color Saturation | Rg=99 | ||||||||||||
| Lumen output | Lamp lumen 100lm/W | Download | |||||||||||
| Materials | Die cast Aluminum |  | |||||||||||
| Installation | Recessed | ||||||||||||
| Protection | IP20 | ||||||||||||
| Finish | White/Black | ||||||||||||
| Warranty | 3 years | ||||||||||||
Application Scenarios
Widely used in high-end commercial interiors such as international schools, corporate lobbies, luxury retail stores, art galleries, hotel reception areas, and exhibition centers.
