SRC-F Trim Profile Recessed Magnetic Track Rail 24V/48V

The SRC-F low-profile recessed magnetic track, specifically engineered for ceiling plenums up to 31.2mm deep, is constructed from 6063-T5 industrial-grade aluminum extrusion with a 22.8mm inner slot to ensure precise module fitment. Supporting a single-circuit maximum load of 768W under 24V/48V DC for continuous runs of up to 40 meters, it perfectly resolves the common limited-plenum challenge in renovation projects for offices, retail stores, and villas by enabling seamless flush-mounting without sacrificing ceiling height. For loads approaching the 768W ceiling or runs exceeding 40 meters, pairing it with our proprietary 48V high-power driver and the STC9006~9010 L/T/cross connectors effectively prevents long-distance voltage drops. Serving as the foundational skeleton for the Magnetic Track Light V4 system, it seamlessly accommodates spotlights, grilles, and globe modules, while every unit rigorously undergoes a 48-hour cyclic high/low-temperature aging test prior to shipment to guarantee long-term operational stability and electrical safety on-site.

Key Feature

 Power Capacity: The SRC-F aluminum track delivers a 768W maximum system load via 24/48V DC, supporting a continuous run of up to 40 meters from a single power feed. This capacity reliably drives multiple magnetic fixtures simultaneously, ensuring stable electrical distribution for expansive commercial ceilings and retail displays without experiencing line-loss or voltage drops.

Installation & Modular Layouts: The SRC-F features a 5mm face trim, supporting both recessed and pendant suspension installations. Utilizing the STC9001F to STC9005F connector series, it allows the creation of complex L-shape, T-shape, and cross-grid configurations, easily adapting to multi-directional layouts in hotel lobbies and high-end offices.

Thermal Management: Constructed with an industrial-grade extruded aluminum profile, this track utilizes metal conductivity to dissipate operating heat. Even under a sustained 768W full load, it maintains a low working temperature for magnetic modules and power conductors, significantly extending the lifespan of attached 24V/48V DC lighting units.

Contact us for project pricing or OEM samples.
